Universal safety heating bath for water and oil applications. With integrated carrying handles and safety temperature circuit. The HB 10 heating bath also comes with a built in dry- run control. It stops heating the bath if no medium is present. Laterally arranged carrying handles allow for safe handling without the risk of burns. Additionally, the newly added lock function prevents accidental change of bath settings. HB 10 has an accuracy of +/-1 Kelvin. The optimized 3 liter bath shape is adapted to IKA rotary evaporator glassware. It therefore guarantees the fastest heat-up times. The heating bath HB 10 is designed with high-quality, recyclable materials and therefore contributes to resource-preserving production. Protection shield and protective cover can be added as accessories.

Universal use for both water and oil

Ergonomically designed handles

Safety temperature cut off

Integrated dry-run control

Lock function prevents accidental change of set conditions

Micro-controller temperature control

Accuracy +/-1 Kelvin

Heater power 1300 Watt

Optimized bath volume guarantees fast heat-up

Designed to work with IKA rotary evaporators

技術參數：       訂貨號 0004068000

加熱輸出功率：     1300 W

加熱溫度范圍：     室溫 - 180 °C

加熱溫度控制：     LCD

加熱溫度控制精確度：         1 ±K

調節器波動(3升水/90°C)：        1 ±K

調節器波動 (3升硅膠油 / 50mPas / 150°C)：          2 ±K

浴槽最大容量：     3 l

最小注水點：         50 mm

物料接觸部分材料：     不銹鋼 1.4404

固定安全溫度回路：     180 °C

可調安全溫度回路最小值：         50 °C

可調安全溫度回路最大值：         190 °C

DIN 12877安全級別：  II

外部高度：     185 mm

內部高度：     134 mm

外形尺寸：     295 x 190 x 265 mm

重量：     3 kg

允許環境溫度：     5 - 40 °C

允許相對濕度：     80 %

DIN EN 60529 保護方式：    IP 21

RS 232接口：          不

USB接口：     不

模擬輸出：     不

電壓：     220 - 240 / 100 - 120 /

100 V

頻率：     50/60 Hz

儀器輸入功率：     1350 W
